230 Vac
230 Vac self-locking electromechanical operator | Design and striking lines, particularly suitable for wrought iron gates | Easy and quick installation thanks to small dimensions and low installation height | Spindle with scraper ring, protected by stainless steel rod, making the system suitable for dusty or sandy environments or places exposed to harmful weather conditions | Unlocking from above with easy access | Available in right or left-hand versions
2x BILL30M
230 Vac self-locking electromechanical drive
1X HEADY
230 Vac control unit with integrated receiver
1X PUPILLA.T
Pair of photocells can be aligned in three positions, power supply 14÷30 Vac / 12÷30 Vdc | Close mounting of 2 pairs is possible without synchronization
1X LAMPY
Flashing light 12 ÷ 255 Vac / 14 ÷ 255 Vdc with integrated antenna
1X TO.GO2VA
Hand-held transmitter with 2 channels, 433.92 MHz, with Advanced Rolling Code and Rolling Code
| Supply voltage motor | 230 Vac (50-60Hz) |
| Max. Power consumption | 1,1 A |
| Max. Thrust | 2800 N |
| Opening hours | 16″ |
| Standard hub | 300 mm |
| Max. Stroke | 320 mm |
| ED | 30% |
| Protection class | IP54 |
| Integrated control | Nope |
| Encoder | Nope |
| Operating temperature | -20°C /+50°C |
| Lubrication | BOLD |
| Max. Wing length | 2,5 m |
| Weight | 6.1 kg |
| Quantity per pallet | 62 |
| Weight of the set | 14.6 kg |
| Number of sets per pallet | 40 |
APPLICATION
1 to 2 operators for swing gates, opposing sliding gates, hydraulic operators and industrial folding gates
SUPPLY OF THE CONTROL UNIT
230 Vac – 50/60 Hz
SUPPLY OF THE MOTOR
230 Vac / 600 W + 600 W
MAIN FUNCTIONS
Integrated LCD display | Integrated 433.92 MHz radio receiver with 64 codes and 3 radio codings (advanced rolling code, rolling code, fixed code) | Removable terminal blocks | Automatic, semi-automatic or dead man function logic | Encoder input for obstacle detection | Separate limit switch inputs for each motor | Inputs for opening, closing, pedestrian door, step mode, stop | Separate inputs for photocell active on open-close and photocell only active on close | Input for safety contact strip N.C. or 8K2 | Output for electric lock 230 Vac and 12 Vac/dc | Configurable outputs such as “door open” indicator light, auxiliary light, second radio channel and photocell test | Output for flashing light connection | Autoset for operating parameters (motors with encoder) | Electronic setting of torque (separately for each motor) and operating times | Adjustable slowdown | Possibility of parameter configuration and hand transmitter management via the Advantouch system | Number of movements | Access password for programming | Maintenance message
APPLICATION
1 to 2 operators for swing gates
SUPPLY OF THE CONTROL UNIT
230 Vac – 50/60 Hz
SUPPLY OF THE MOTOR
230 Vac / 500 W + 500 W
MAIN FUNCTIONS
Integrated LCD display | Integrated 433.92 MHz radio receiver with 64 codes and 3 radio codings (Advanced Rolling Code, Rolling Code, Fixed Code) | Removable terminal blocks | Automatic, semi-automatic function logic | Input for step operation, pedestrian door and stop | Separate inputs for photocell programmable for activation on opening-closing or only on closing | Output for 230 Vac electric lock/auxiliary lighting | Output for “gate open” indicator light, second radio channel and photocell test | Output for flashing light connection | Electronic setting of torque (separately for each motor) and operating times | Fixed slowdowns | Possibility of parameter configuration and hand transmitter management via the Advantouch system | Number of movements | Access password for programming | Maintenance message
