CORE

APPLICATION

1 operator for sliding gate or 1 gate leaf

SUPPLY OF THE CONTROL UNIT

230 Vac – 50/60 Hz

SUPPLY OF THE MOTOR

230 Vac / 750 W

MAIN FUNCTIONS

Setting of parameters and operating logic with trimmers and dip switches | 433.92 MHz radio receiver with 64 codes and 3 integrated radio codes (advanced rolling code, rolling code, fixed code) | Removable terminal strips | Automatic and semi-automatic operating logic and dead man function | Input encoder MAG.E input for obstacle detection | Inputs for motor limit switches | Inputs for step mode, stop, light barrier | Step mode input configurable as opening | Stop input configurable as closing or pedestrian door | Light barrier input programmable for activation on opening-closing or only on closing | Output for “door open” indicator light | Output for flashing light connection | Autoset operating parameters and slowdowns | Adjustable slowdown | Electronic adjustment of motor torque (5 levels) | Management of hand transmitters stored in the integrated receiver possible via Advantouch system
