24 Vdc | Intensive operation
24 Vdc barrier for intensive use with integrated control unit and battery charger | 100÷250 Vac switching power supply for low power consumption and long service life of the operator | AISI 304 stainless steel finish | Easy installation and quick connection possibility for an operating mode with opposing trees thanks to the optional SIS board | Low consumption in standby mode | Possibility of installing FTC.S photocells, which fit perfectly thanks to the concealed installation system | Simple, fast and reliable system for tree balancing | Adjustable slowdowns
Delivery without foundation plate
Controls
CP.LADY
APPLICATION
1 road barrier series LADY, LADY.5, VE.650
SUPPLY OF THE CONTROL UNIT
100 ÷ 250 Vac – 50/60 Hz
SUPPLY OF THE MOTOR
24 Vdc / 10 A
MAIN FUNCTIONS
Integrated LCD display | Integrated 433.92 MHz radio receiver 64 codes and 3 radio codings (advanced rolling code, rolling code, fixed code) | Removable terminal strips | Automatic, semi-automatic and dead man function logic | Motor limit switch inputs | Inputs for open, close, stop, step operation, photocell | Output for LADY.L, LEDs integrated in the barrier boom | Output configurable as barrier open indicator light, second radio channel of the built-in receiver, barrier lights, auxiliary lights, light barrier test or maintenance light | Output for flashing light connection | Preparation for “opposite barriers” operation using SIS synchronization card (optional) | Autoset operating parameters | Crush protection with force cut-off | Adjustable slowdown | Number of movements | Access password for programming | Maintenance message | Integrated battery charger, compatible with batteries Mod. DA.BT2/DA.BT6
