TRUST24

APPLICATION

1 to 2 operators for swing gates

SUPPLY OF THE CONTROL UNIT

100 ÷ 250 Vac – 50/60 Hz

SUPPLY OF THE MOTOR

24 Vdc / 130 W + 130 W

MAIN FUNCTIONS

Built-in LCD display | Built-in 433.92 MHz radio receiver with 512 codes and ARC radio coding | Removable terminal blocks | Separate limit switch inputs for each motor | Automatic, semi-automatic and dead man operating logic | Separate encoder inputs for each motor | Inputs for open, close, step, pedestrian and stop | Input for photocells active on open-close and photocells active on close only | Input for safety contact strip N.C. or 8K2 | Output for 12/24 Vdc electric lock | Two outputs configurable as indicator light for open door, auxiliary light, zone light, second radio channel, light barrier test, flashing light | Autoset of operating parameters | Separate electronic torque adjustment for each motor | Crush protection with force cut-off and encoder management | Electronic torque adjustment with automatic calculation for each travel point (STC SYSTEM) | Separately adjustable decelerations for each motor | Possibility of encoder or timed operation (managed via virtual encoder) also independently between the two motors | Integrated ESA+ for energy saving | Prepared for KNX connection via X.BE (optional) | Prepared for control, configuration, diagnostics and firmware update via the BeUP app, via the PRO.UP accessory | Possibility of configuring parameters and managing handheld transmitters with the Advantouch system | Number of maneuvers | Access and programming password | Maintenance message | Integrated battery charger | Standby consumption in accordance with European Regulation (EU) 2023/826
