230 Vac drive with electronic control with integrated receiver and encoder
230 Vac
230 Vac operator with electronic control unit with integrated receiver and encoder | The encoder offers crush protection and precision in door movement | Smoother running thanks to the control unit with autotransformer to reduce door vibrations to a minimum | Integrated auxiliary light, limit switch and command buttons
| Mains supply | 230 Vac (50-60Hz) |
| Supply voltage motor | 230 Vac |
| Max. Power consumption | 1,4 A |
| Torque | 330 Nm |
| Opening hours | 22″ |
| ED | 30% |
| Protection class | IP40 |
| Integrated control | Yes |
| Integrated receiver | Yes |
| Encoder | Yes |
| Operating temperature | -20°C /+50°C |
| Max. Door surface 1 motor (2 motors) | 12,5 ㎡ (16 ㎡) |
| Weight | 9.9 kg |
| Quantity per pallet | 50 |
APPLICATION
1 or 2 actuators ZED.RIE or ZEDL.RIE series
SUPPLY OF THE CONTROL UNIT
230 Vac – 50/60 Hz
SUPPLY OF THE MOTOR
230 Vac / 300 W + 300 W
MAIN FUNCTIONS
Integrated LCD display | Integrated 433.92 MHz radio receiver with 64 codes and ARC radio coding | Removable terminal blocks | Automatic, semi-automatic and dead man function logic | Encoder input for obstacle detection | Separate limit switch inputs for opening and closing a motor | Inputs for stepping, closing and stopping | Input for N.C. or 8K2 safety contact strip | Light barrier input programmable for activation on opening-closing or only on closing | Output for 24 Vdc auxiliary light or 8K2 safety contact strip | Programmable photocell input for activation on opening-closing or only on closing | Output for 24 Vdc auxiliary light | Autoset operating parameters for ZED series motors with encoder | Electronic torque adjustment (4 levels) | Autoset operating parameters and deceleration | Adjustable deceleration | Possibility of parameter configuration and remote control management via the Advantouch system | Number of movements | Access password for programming | Maintenance message
